Description
Arc-head control for larger tubulars in the Americas
The Drill Pipe Casing Tool is a long-handled positioning aid for larger drill pipe, casing, conductor and bundles of drill pipe. Its arc-shaped head provides a broad pushing contact, while the integrated tag-line retrieval hook adds a pull function. The official specification describes use with larger tubulars up to 12 inches on rig floors, catwalks and V-door areas. CK Loosbrock USA can support model selection, documentation and quotation requirements across the Americas.
Best suited for
- Large drill pipe and casing joints up to the manufacturer-stated 12-inch limit.
- Conductor and bundles of drill pipe reviewed within the handling plan.
- Rig-floor, catwalk and V-door positioning tasks.
- Selected fishing tools suited to the arc-head contact geometry.
- Operations using tag lines to stabilize a suspended load before tool engagement.
Choosing length and handle configuration
The official specification sheet lists 1200 and 1500 mm enclosed-handle models and a 1500 mm open-handle model. Select the configuration according to the pipe or bundle geometry, desired engagement point, work-area clearance and the operator position defined by the lift plan. An open grip should not be assumed interchangeable with an enclosed grip for every task. Custom lengths are described as available on request, subject to manufacturer confirmation.
Why source through CK Loosbrock USA
- Configuration review based on tubular diameter, bundle form and required reach.
- Support distinguishing the Casing Tool from smaller pipe-handling heads.
- Access to the official manufacturer specification and operating limitations.
- Americas-focused quotation support and delivery coordination.
Manufacturer specifications and features
| Model | Product code | Hand grip | Length |
|---|---|---|---|
| Drill Pipe Casing Tool | DPCT18007 | Enclosed | 1200 mm |
| Drill Pipe Casing Tool | DPCT18008 | Enclosed | 1500 mm |
| Drill Pipe Casing Tool | DPCT19008 | Open | 1500 mm |
- Arc-shaped attachment for casing, conductor and bundles of drill pipe.
- Tag-line retrieval hook providing the manufacturer’s described pull function.
- Medium-density polyethylene head and 30 mm marine-grade aluminium staff.
- Hi-visibility attachment, hand protector and durable foam-rubber grip.
- Replaceable non-slip, low-compression rubber grommets.
Application guidance
Stabilize the suspended tubular or bundle with tag lines before approaching with the Casing Tool. Engage the arc-shaped head face-on at approximately waist level and use it for the controlled push function defined in the handling plan. Use the tag-line hook only for the retrieval or pull function described by the manufacturer. Maintain communication with the banksman and lifting-equipment operator, and remove the tool only when the load has reached the planned position and the procedure permits.
Safety and use limitations
- Wear the personal protective equipment required for the work area and task.
- Only engage casing or drill-pipe bundles when positioned at approximately waist level.
- Stabilize swinging loads with tag lines from a safe position before engaging the tool.
- Never stand beneath a suspended load or enter its travel path.
- Check that bundle arrangement and individual tubulars are controlled by the approved lift plan.
- Engage the arc head face-on and keep both hands in the designated grip area.
- Do not use the tool for prying or leveraging activities.
- Inspect the head, hook, staff, grip and grommets before use.
Available documentation
Frequently asked questions
What is the maximum stated tubular diameter?
The manufacturer specification describes larger drill pipe and casing joints up to 12 inches. Confirm actual outside diameter and geometry.
What does the arc-shaped head do?
It provides the broad contact used for the pushing function on larger pipe, casing, conductor and reviewed bundles.
Can the tool pull a load?
The manufacturer describes the tag-line retrieval hook as providing pull control. Use it only within the approved positioning procedure.
Which standard configurations are documented?
Documented standard options are enclosed handles at 1200 and 1500 mm, plus an open handle at 1500 mm.
What information supports correct selection?
Provide tubular type, outside diameter, single or bundle configuration, orientation, required reach, preferred grip, quantity and destination.
Request current documentation, configuration guidance and a quotation for the Drill Pipe Casing Tool from CK Loosbrock USA.
Compare the 10” PRO Pipe Handling Tool and Drill Pipe Handling Tool, or view the Hands Free Working range.
Request Availability and Pricing
Contact CK Loosbrock for current availability, pricing, model selection or specific handling requirements for Drill Pipe Casing Tool.
Please include the required product code, quantity and delivery location with your enquiry.
