Description
Two-person drill-pipe alignment support for the Americas
The Drill Pipe Connection Guide is a two-part tool used by two personnel during drill-pipe make-up on the drill floor. The matching halves close around the selected pipe diameter so the stand can be guided while hands remain on the tool handles. Its inner rubber surface is also described for wiping drilling fluid when pulling out of the hole. CK Loosbrock USA can help customers across the Americas identify the diameter-specific product code and current manufacturer information.
Best suited for
- Two-person control of a drill-pipe stand as it engages with the stand in the rotary slips.
- Connection work where the driller needs a clear view of alignment.
- Diameter-specific drill pipe from 2⅜ through 5⅞ inches.
- Pull-out operations where the internal rubber surface is included in the approved wipe-down plan.
- Drill-floor procedures designed to keep hands away from the pipe and connection pinch points.
Select by actual pipe diameter
Every listed Drill Pipe Connection Guide is assigned to one nominal pipe diameter. Verify the drill-pipe outside diameter and connection program before selecting a code. Do not choose a larger guide as a universal substitute, and do not assume nominal pipe size from the connection alone. The tool consists of two identical working parts, so confirm that the complete matched set, wrist lanyards and quick-disconnect features are present before the job begins.
Why source through CK Loosbrock USA
- Product-code confirmation against the pipe diameter schedule.
- Support requesting current manufacturer use and inspection information.
- Quotation and delivery coordination for operations in the Americas.
- Help comparing connection, wipe-down and general pipe-positioning tools.
Manufacturer size range and construction
| Product code | Drill-pipe diameter |
|---|---|
| DPCG18009 | 5⅞ inches |
| DPCG18010 | 5½ inches |
| DPCG18011 | 5 inches |
| DPCG18012 | 4½ inches |
| DPCG18013 | 4 inches |
| DPCG18014 | 3½ inches |
| DPCG18015 | 3 inches |
| DPCG18016 | 2⅜ inches |
- Two identical parts intended to be operated by two personnel.
- Handle layout intended to keep operators away from connection pinch points.
- Chemical-resistant, reinforced rubber described by the manufacturer.
- Wrist lanyards intended to reduce the risk of dropping a part downhole.
- Quick-disconnect devices for the rotating-equipment hazard identified by the manufacturer.
Application guidance
Use the guide only within the drill-floor make-up procedure approved for the rig. Assign one trained person to each half and establish commands with the driller before approaching the stand. Bring the matching halves around the pipe, maintain balanced control and keep the driller’s line of sight clear. When the inner rubber surface is used during pull-out, include fluid containment and exposure controls. The manufacturer’s public page describes the function but does not replace a task-specific operating procedure.
Safety and use limitations
- This is a two-person drill-floor tool. Do not substitute one-person operation.
- Use only the model matched to the verified drill-pipe diameter.
- Keep hands and body parts outside the pipe, connection and rotary-equipment pinch zones.
- Inspect both tool halves, rubber surfaces, lanyards and quick disconnects before use.
- Use wrist lanyards and quick-disconnect features only as directed by current site and manufacturer procedures.
- Wear PPE selected for drilling-fluid contact, impact and drill-floor hazards.
- Stop if communication with the driller or the second operator is lost.
- Do not treat the guide as a lifting, torque or pipe-support device.
Available documentation
Frequently asked questions
How is the correct guide selected?
Match the verified drill-pipe outside diameter to the manufacturer’s product-code table. Eight sizes from 2⅜ to 5⅞ inches are listed.
How many people operate the tool?
The official product page specifies two personnel, one for each identical part of the guide.
Why are quick disconnects fitted?
The manufacturer identifies them as a control for risks to personnel limbs associated with rotating equipment. Follow the current procedure for their use.
Can the inner rubber surface wipe drilling fluid?
Yes, that function is described for pulling out of the hole. Fluid-specific PPE, hygiene and containment controls still apply.
What details are needed for an enquiry?
Provide pipe diameter, rig and connection context, required quantity of complete sets, documentation requirements and delivery location.
Request current documentation, diameter confirmation and a quotation for the Drill Pipe Connection Guide from CK Loosbrock USA.
Related products include Pipe Wipe Pro and the Drill Pipe Handling Tool. Browse the Hands Free Working range.
Request Availability and Pricing
Contact CK Loosbrock for current availability, pricing, model selection or specific handling requirements for Drill Pipe Connection Guide.
Please include the required product code, quantity and delivery location with your enquiry.
sales-usa@ckloosbrock.com
sales-europe@ckloosbrock.com
As the official stocking distributor for Offshore Handling Systems in the Americas, We maintain inventory ready to ship directly from our facility in Conroe, Texas.
